KK50 Linear Stage

KK50 Linear Stage(With Protective Cover)

The KK50 Linear Stage With Protective Cover is a high-performance, integrated linear motion system. It is specifically designed for high-precision, medium-to-heavy-load applications in demanding industrial environments.

This unit is categorized as a Sealed or Enclosed Ball Screw Actuator. In this configuration, the sensitive internal drive and guide components are protected by a continuous sealing system, effectively combining high precision and repeatability with maximum durability against contaminants.

Manufacturing Processes

Manufacturing focuses on the dimensional accuracy of the heavy profile and the precise alignment required for high-speed operation:

Precision Profile Machining: The aluminum body is accurately CNC-machined. The internal guide rail and ball screw mounting surfaces are machined to the tightest possible parallelism and flatness tolerances to ensure smooth high-speed travel.

Component Integration: The guide rail(s) and the ball screw are meticulously installed. The critical step is ensuring the guide axis and screw axis are absolutely parallel to prevent binding at high speeds, which would generate excessive heat and wear.

Dynamic Calibration: The final stage undergoes laser calibration and dynamic performance testing. This verifies not only the positional accuracy but also the maximum achievable speed, acceleration, and thermal stability under continuous operation.
