HGW Series Linear Guide

HGW Series Linear Guide

The HGW Series is categorized as a Wide, High-Load Recirculating Ball Profiled Rail Guide. It is built on the robust rail structure of the standard HG Series but utilizes a wider bearing block to optimize performance against lateral and torsional forces.

Its primary functions include:

1.Maximum Torsional Moment Resistance: The extra-wide block significantly increases the moment arm (the distance between the points of resistance), which provides superior rigidity against torsional (twisting) moments and yaw moments compared to the standard HGH block.

2.High Load Capacity with High Stability: It is capable of carrying the massive loads of the standard HGH while offering enhanced stability, making it ideal for systems with overhung or unbalanced loads.

3.Single-Rail Systems: The HGW's exceptional resistance to overturning moments allows it to be frequently used as a single rail system for carriages, simplifying machine design and installation in wide-span applications.

The HGW Series is a critical component in large-scale machinery, including large CNC gantry machines, heavy material handling equipment, and precision transfer lines.

Manufacturing Processes

The HGW manufacturing process adheres to the highest standards of precision grinding and heat treatment, with added attention to the large block's geometry:

Material and Hardening: High-grade bearing steel is used. Both the rail and the block are subjected to intensive heat treatment (hardening) to achieve a high surface hardness (HRC 58-62), which is vital for the system's longevity and load-bearing performance.

Precision Grinding: The CNC grinding of the Gothic arch raceways is performed to achieve a mirror finish and micrometer-level geometric accuracy. The large, wide top flange of the block is also precision-ground to ensure exceptional flatness and parallelism for the load mounting surface.

Preloading and Assembly: A precise preload is applied to the rolling elements during assembly. This preloading is essential for eliminating internal clearance (backlash), which is the foundation for the high rigidity and excellent repeatability that the HGW series delivers.

Quality Control: The final mounted units undergo stringent inspection to verify running parallelism, moment stiffness, and dimensional accuracy, confirming their suitability for heavy-duty, precision applications.
