RGW Series Linear Guide

RGW Series Wide-Flange Roller Linear Guide

The RGW Series is a wide-flange, heavy-duty roller linear guideway system engineered for industrial machinery demanding high load capacity, superior rigidity, and enhanced resistance to torsional and overturning moments.

Line-Contact Roller Mechanics
Departing from conventional ball-type guides, the RGW Series utilizes precision-ground cylindrical rollers as its rolling elements. This arrangement establishes a solid "line contact" interface with the raceways, creating an expanded contact area that substantially reduces elastic deformation under heavy dynamic and static loads.

Wide-Stance Structural Stability
A primary characteristic of the RGW Series is the integration of cylindrical rollers into an expanded wide-flange carriage block. This wider footprint increases the effective support width along the guideway, making it exceptionally resilient against roll, pitch, and yaw moment loads. It is specifically engineered to stabilize wide carriages, offset loads, and cantilevered tooling assemblies where motion fidelity is critical.

Applications & Custom Manufacturing
Typical Applications: Large CNC machine tools, gantry milling systems, precision surface grinders, heavy industrial automation, and high-tonnage transfer equipment.
Custom OEM/ODM Services: Yongrun Precision provides comprehensive OEM and customized production based on customer drawings, technical specifications, and specific application requirements.

Factory-Direct OEM Guideway Solutions
Don't compromise your machine frame to fit standard catalog dimensions. Yongrun Precision partners with machinery manufacturers and system integrators to deliver custom-manufactured RGW roller guideways that fit your exact blueprints.

Engineered to Your Drawing: Send us your 2D prints, 3D CAD files, or reference samples. We manufacture guide rails and carriages to your required dimensions, hole layouts, and mounting configurations.
Matched to Your Load Requirements: Whether your system requires standard flanged blocks (CC) or extended heavy-duty blocks (HC), our engineering team reviews your dynamic payloads, moment forces, and speeds to ensure optimal stiffness and service life.
Your Brand, Ready for Market: We offer private-label laser marking and custom packaging, delivering components ready for seamless integration into your product line or distribution network.
Factory-Direct Engineering Oversight: Every custom project undergoes a formal technical review by our in-house engineers before production, ensuring accurate tolerances and reliable long-term performance.

Submit your drawings or application specifications today for a detailed technical review and quotation.
