Product descriptions

The PSH (often referred to as PHS) Series Rod End Bearing is a high-quality mechanical articulating joint, also known as a heim joint or rose joint. It is designed to connect rods, linkages, and shafts while accommodating angular misalignment. This series features a female-threaded shank for easy installation and adjustment, providing a crucial and reliable pivot point for transmitting motion and loads in a wide range of mechanical systems.

Construction and Design:

The bearing consists of a durable, eye-shaped housing with an integral, female-threaded shank. This housing encases a precision spherical plain bearing, which allows for the pivoting and angular movement. This series is designed for applications requiring periodic maintenance (lubrication) and is particularly suitable for supporting radial forces in both tensile (pulling) and compressive (pushing) directions.

Key Features and Advantages
Engineered for durability and high performance, the PSH Series Rod End Bearing offers several key benefits for mechanical linkages.

Accommodates Angular Misalignment: Its primary function is to allow for angular misalignment between connected components. The internal spherical ball prevents binding and reduces stress in the linkage, ensuring smooth operation.

Female Threaded Shank for Easy Adjustment: The internal (female) thread design allows for straightforward attachment to threaded rods and provides a simple, effective method for adjusting the length of linkages.

Robust and Corrosion-Resistant Construction: The housing is typically made from zinc-plated steel for corrosion resistance. The spherical bearing often features a steel-on-bronze or steel-on-steel sliding surface combination, providing high load capacity and durability.

Designed for Lubrication and Heavy Loads: This series is designed to be relubricated periodically, making it highly resistant to wear and ideal for applications with heavy, alternating, or shock loads. The steel-on-bronze variants, in particular, offer excellent performance even under conditions of temporary lubricant starvation.

High Load Capacity: PSH rod ends are built to handle significant static and dynamic loads, making them a reliable choice for demanding industrial applications.

Versatile Application: These bearings are crucial components in a wide range of machinery, facilitating smooth and precise oscillating, pivoting, and rotational movements.
