SFY01632 Ball Screw

SFY01632 Ball Screw

Product descriptions

The SFY01632 Ball Screw is a high-performance linear drive component engineered specifically for applications demanding ultra-high-speed travel and rapid linear displacement.

Belonging to the specialized High-Lead series, this model features a unique 1:2 diameter-to-lead ratio, pairing a compact 16mm nominal diameter with an aggressive 32mm lead. This distinct geometry allows the nut to travel a full 32mm with every single 360-degree revolution of the screw. By achieving exceptional linear velocities at relatively low motor RPMs, the SFY01632 effectively minimizes heat generation, centrifugal wear, and system vibration. It stands as an essential drive solution for modern, high-throughput automated systems where speed and efficiency are paramount.

Specification

Operating Principles:

The SFY01632 operates on the principle of recirculating ball mechanics, optimized to achieve nearly frictionless, high-speed linear conversion.

1.Rotary-to-Linear Transformation: As a servo or stepper motor applies torque to the screw shaft, precision-grade steel balls roll within the helical raceways formed between the shaft and the flanged nut. This rolling contact converts rotary motion into axial thrust with exceptional efficiency.

2.High-Pitch Displacement: Characterized by a steep helix angle (a 32mm lead), a single rotation propels the nut forward at a significantly accelerated rate compared to standard screws.

3.End-Cap Recirculation: To accommodate high velocities, the SFY01632 utilizes a specialized End-Cap return system. As the balls exit the load-bearing circuit, the end caps efficiently collect and route them through internal return channels back to the starting point, ensuring a smooth, continuous, and high-speed rolling loop.
