HGW65CC Linear Guide

HGW65CC Linear Guide

Product Description

The HGW65CC is a high-rigidity, flanged linear motion carriage from the HG Heavy Load Series. Engineered for large-scale, high-precision industrial machinery operating under substantial loads, this block is specifically designed to slide along a standard 65mm width profile rail (such as the HGR65 series).

Advanced Engineering & Design

4-Way Equal Load Rating: The carriage incorporates a four-row steel ball recirculation system configured at a symmetrical 45-degree contact angle. This geometry delivers a balanced, omnidirectional load-bearing capacity in radial, reverse-radial, and lateral directions, maintaining structural stability across all axis orientations.

Bi-Directional Flange Mounting: The flanged (W-type) profile features a broad mounting surface with a total width of 170 mm. This wide carriage profile is engineered to accept M16 bolts installed either from the top down or threaded directly from the bottom up, offering versatile mechanical integration for heavy tooling, columns, and gantry carriages.

Company Advantages

1.Extensive Selection & Custom Sizing: We provide an extensive range of models and technical specifications, with product lengths fully customizable to meet your specific requirements.
2.Flexible Minimum Orders: To accommodate prototyping, small batches, and large-scale projects alike, we support a Minimum Order Quantity (MOQ) of just 1 piece.
3.Comprehensive OEM/ODM Support: We offer full OEM and ODM services, including customized packaging and product marking to support your private labeling and branding needs.
4.Complimentary Sampling: We offer free product samples for quality verification, with shipping costs to be covered by the customer.
5.Certified Quality Assurance: Our operations are certified under the ISO 9001 Quality Management System, and our products hold CE certification, backed by a comprehensive 2-year warranty.
