RGW55CC Linear Guide
RGW55CC Linear Guide
Product Description
The RGW55CC is a high-rigidity, flanged-type linear guide block engineered for heavy-duty CNC machining, portal mills, and large-scale industrial gantries. Part of the performance-driven RG Series, it utilizes precision-ground cylindrical rollers instead of traditional steel balls, offering line-contact geometry that provides superior stiffness and vibration suppression.
Designed for standard RGR55 rails, the RGW55CC features a wide flange design that provides excellent moment-load resistance and supports versatile top-down or bottom-up mounting configurations, offering an adaptable, robust foundation for demanding industrial machinery.
| product name | linear guide RGW55CC |
| material | Gcr15 |
| model number |
RGW25CC, RGW25HC, RGW30CC, RGW30HC, RGW35CC, RGW35HC, RGW45CC, RGW45HC, RGW55CC, RGW55HC, RGW65CC, RGW65HC |
| Preload Classes Available | Z0 (Light), ZA (Medium), ZB (Heavy) |
| Accuracy Classes Available |
H (High), P (Precision), SP (Super Precision), UP (Ultra Precision) |
Product Advantages
1.Superior Structural Rigidity: The roller design reduces elastic deformation by up to 50% compared to standard ball-type blocks , ensuring high carriage stability under heavy cutting forces.
2.Excellent Vibration Damping: The larger contact area of the rollers inherently dampens harmonic vibrations, resulting in refined workpiece surface finishes and extended tool life.
3.Heavy-Duty Load Management: Specifically engineered for heavy-load (CC) scenarios, the assembly manages static loads of several hundred kilonewtons while maintaining target speed and accuracy.
4.Extended Precision Life: By distributing contact stress along a line rather than a point, the RGW55CC prevents localized rail fatigue and extends the maintenance-free service life.
5.Advanced Sealing System: Equipped with reinforced double-lip end seals, side seals, and bottom seals to effectively block out metal shavings, abrasive dust, and high-pressure coolants.
